Rapid prototyping manufacturer cnc SLA/ABS 3d printing service
| Material | Resin 9400 | Imported Resin 8000 | Transparent Resin | High Tenacity Resin | Yellow HTR | Grey HTR | Black Nylon PA12 |
| heat distortion temperature (0.46MPa) | 46 | 46 | 47 | 38-50 | 70 | 99.6 | 173 |
| Min Wall Thickness | 0.6mm | 0.6mm | 0.6mm | 0.6mm | 0.6mm | 0.6mm | 0.5mm |
| Min Hole Diameter | 1mm | 1mm | 1mm | 1mm | 1mm | 1mm | 1.2mm |
| Materal Hardness (Shore D) | 79 | 79 | 87 | 85 | 80 | 85 | 86 |
| Extension Strength (Tensile) | 47MPa | 47MPa | 50MPa | 38-56MPa | 48MPa | 40-44MPa | 50MPa |
| Extension Strength (Fracture) | 33-40MPa | 33-40MPa | 56MPa | 60MPa | 56MPa | 52MPa | 70MPa |
| Bending Strength | 67MPa | 67MPa | 84MPa | 69-74MPa | 68MPa | 64-69MPa | 75-80MPa |
| Bending Modulus(MPa) | 2178-2222 | 2178-2222 | 2490 | 2692-2775 | 2300 | 2900-3200 | 2800 |
| Printing Height | 0.1/0.05 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 | 0.1 |
| Printing Error Range | 3/1000 | 3/1000 | 3/1000 | 3/1000 | 3/1000 | 3/1000 | 2.5/1000 |
| Moisture Absorption | 4/1000 | 4/1000 | 4/1000 | 4/1000 | 4/1000 | 4/1000 | |
| Impact Strength | 23-29J/CM | 23-29J/CM | 25J/CM | 45-29J/CM | 33J/CM | 34.4J/CM | 2.7KJ/CM |
