Oem Custom Metal Milling Turning Service Aluminum Cnc Machining Parts With Laser Cutting

CNC Machining Advantage


✔ Instant Quotes & DFM(Design for Manufacturing) Feedback
✔ Parts as Fast as 2 days
✔ Tight Tolerances
✔ Hand Metrology, Laser & CMM Inspections




CNC Machining Process

CNC Milling

3, 4 and 5-axis machining capabilities for simple and complex geometries.

CNC Turning

Standard and live tooling capabilities for cylindrical parts such as pins, shafts, and spacers.




Precision Machining Tolerance
With a drawing, We can produce parts with tolerance as low as +/- 0.0002 in. Without a drawing, all parts are produced to our ISO 2768 medium standard.
Description
Tolerance
Linear Dimension
+/- 0.025 mm
+/- 0.001 inch
Hole Diameters (Not Reamed)
+/- 0.025 mm
+/- 0.001 inch
Shaft Diameters
+/- 0.025 mm
+/- 0.001 inch
Smallest Thread Size Available
M1x0.25



CNC Surface Finishing Options
Alodine
Chromate conversion coating, more commonly known by its brand name Alodine, is a chemical coating that passivate and protects aluminum from corrosion. It is also used as a base layer before priming and painting parts.

Colors:Clear, Gold
Anodizing
Anodizing is an electrolytic passivation process that grows the natural oxide layer on aluminum parts for protection from wear and
corrosion, as well as for cosmetic effects.
Colors:Clear, black, grey, red, blue, gold
Types:Type 2, Type 3, Type 3 + PTFE
Texture:Smooth, matte finish. Does not cover machine marks unless media blasted beforehand.
Black Oxide
Black oxide is a conversion coating similar to Alodine that is used for steel and stainless steel. It is used mainly for
appearance and for mild corrosion resistance.

Colors:Black
Texture:Smooth, matte black
Brushing
Brushing is a metal processing process. Under the action of external force, the metal is forced through the mold, the cross-sectional area of the metal is compressed, and the technical processing method of obtaining the required cross-sectional area shape and size is called the metal drawing process.
Chemical polishing
Aluminium chemical polishing is widely used in the lighting industry, where the parts geared to reflect light gain in terms of light output and saving energy consumption; and for home and bath accessories, instead of chrome plating (which is more expensive and less workable).
Chrome Plating
Brushing is the manufacturing process of repeatedly scraping the metal out of lines with sandpaper. In the wire drawing process, the special coating technology after anodizing can make the metal surface produce a coating layer containing the metal component, clearly showing each minute Silk marks, so that fine hair shines in the metal matte, to play a beautiful, anti-erosion effect.
Electroless Nickel Plating
Electroless nickel plating (ENP) is a reaction that deposits a nickel-phosphorus alloy onto the surface of a metal. Compared to electroplating, it has more uniform thickness and superior wear and corrosion resistance.

Texture:Smooth, glossy finish
Electropolishing
Electropolishing is an electrochemical process used to improve the surface finish of a part by removing material to level microscopic peaks and valleys.

Texture:Smooth, glossy finish
Media Blasting
Media blasting uses a pressurized jet of abrasive media to apply a matte, uniform finish to the surface of parts.

Texture:Matte
Nickel Plating
Nickel plating is a process used to electroplate a thin layer of nickel onto a metal part. This plating can be used for corrosion and wear resistance, as well as for decorative purposes.

Texture:Smooth finish
Paint Spraying
Spraying is a coating method in which spray gun or dish atomizer is used to disperse into uniform and fine droplets by means of pressure or centrifugal force and apply to the surface of the object to be coated. It can be divided into air spraying, airless spraying, electrostatic spraying and various derivative methods of the above basic spraying forms.
Passivation
Passivation is a chemical reaction that causes a material to be less affected by corrosion or other environmental factors.

Texture:Smooth, glossy finish
Power coating
Powder coating is a process in which a dry powder paint is applied to a metal surface. Unlike traditional, liquid paint, powder
coating does not need a solvent to keep the binder and filler of the paint in liquid suspension.

Tumbling
Tumbling is a finishing process that is used to clean, deburr, and slightly smooth smaller part.

Texture:Slightly rounded edges, smooth, slightly matte finish, does not hide all machine marks
Zinc Plating
Zinc plating, which is also known as galvanization, is applied to prevent the surface from oxidizing or corroding.
Colors:Clear, light blue coating or glossy black coating
Texture:Smooth finish, does not hide machine marks
Screen Printing
Screen printing refers to the use of silk screen as a plate base, and through the photosensitive plate making method, made into a screen printing plate with graphics and text.
Laser Beam Marking
By adaption of process parameters and the possibility of placing work pieces below the optics which have a height up to 600 mm in maximum permanent marking and scribing is feasible as well on precision parts as on large assemblies. Due to a small track width unlimited contours and patterns are producible.
Our Quality Promise
* Inspection reports included with every order
* All parts inspected using hand metrology, CMM or laser scanners
* All manufacturing partners are highly vetted and managed
* ISO 9001 certified, AS 9100 & ISO 13485 compliant
* Quality guaranteed. If a part is not made to spec, we’ll make it right.
* Material certifications available
